INSTALLATION
12 4111-0013 — Aug. 2007
Dec. 2008
A— Distance (Leveler Frame
Height)
B— Shim Locations (Under
Rear Vertical Supports)
C— Shim Locations (Under
Lip Keepers and Prop)
D— Dock Floor
E— Rear Pit Curb Angle
F— String
G— Rear Hinge Frame Angle
H— Distance (Dock Floor-to-
Pit Floor)
J— Distance (Top of Shim
Stack-to-Dock Floor)
K— Shim Stack
L— Dock Leveler Frame
M — Pyramid (Preferred)
N— Stepped (Acceptable)
P— Offset (Not Acceptable)
Q — Straight (Not Acceptable)
Install Dock Leveler
M
N
P
Q
Shim
Stacking Methods
