PARTS
43
4111-0001 — Oct.2007
Item
Quantity
Part Number
Description
A
1
0522-0005
Clevis Pin
B
1
2101-0045
Cotter Pin
C
1
0522-0156
Yoke
D
1
0521-0005
Roll Pin
E
1
0525-0086
Lip Cylinder, 13-3/4 in. (349 mm) Barrel Length
0525-0087
Lip Cylinder, 20-1/8 in. (511 mm) Barrel Length
F
1
9202-0004
Pin, 3/4 x 4.38 in.
G
2
2101-0049
Clip, Hairpin
H
1
9301-0111
Fitting, #6-ORB Male x #8-JIC Male
J
1
9904-____
1
Hose, Logic Block-to-Lip Cylinder
K
1
9904-____
1
Hose, Pump Pressure Port-to-Logic Block
L
2
2101-0015
Cap Screw, 5/16-18 UNC x 3-1/4 in.
M
2
2101-0039
Nylon Lock Nut, 5/16-18 UNC
N
1
9575-____
3
Logic Block
P
2
2101-0050
Clip, Hairpin
Q
2
9202-0005
Pin, 1 x 3-3/4 in.
R
4
2101-0009
Cap Screw, 5/16-18 UNC x 3/4 in.
S
2
7942-0006
Platform Cylinder, Hold Down
T
1
0525-0043
Cylinder, Platform, 15-1/2 in. (394 mm) Barrel Length
1
0525-0044
Cylinder, Platform, 17-1/2 in. (445 mm) Barrel Length
1
0525-0045
Cylinder, Platform, 19-1/2 in. (495 mm) Barrel Length
1
0525-0046
Cylinder, Platform, 21-1/2 in. (546 mm) Barrel Length
U
1
9301-0120
Elbow, 45° #8-ORB Male x #8-JIC Male
V
1
9904-____
1
Hose, Logic Block-to-Platform Cylinder
W
1
9904-____
1
Hose, Logic Block-to-Pump Return Port
X
2
2101-0040
Nylon Lock Nut, 3/8-16 UNC
Y
2
2101-0060
Washer, 3/8 in.
Z
1
9455-____
2
Hold-Down, Lip Cylinder
AA
1
0522-0002
Spring
AB
1
0521-0007
Elbow, 90° 1/4 NPT Male x 1/4 Tube
AC
2
2101-0011
Cap Screw, 5/16-18 UNC x 1 in.
AD
1
9395-____
3
Power Pack Complete
AE
1
0521-0016
Elbow, 45° 3/8 NPT Male x #8-JIC Male
AF
1
0521-0015
Straight Fitting, 3/8 NPT Male x #8-JIC Male
AG
6
2101-0039
Nylon Lock Nut, 5/16-18 UNC in.
AH
1
9392-0042
Mounting Bar
AJ
1
0521-0007
Elbow, 90° 1/4 NPT Male x 1/4 Tube
AK
4
2101-0011
Cap Screw, 5/16-18 UNC x 1 in.
AL
1
R509-____
1
Tube, Vent (3/8 OD x 1/16 in. Wall)
AM
1
0523-____
2
Lip Lifter
Hydraulic Components
1
Provide length and diameter of hose when calling or faxing orders.
2
Provide length of lip cylinder when calling or faxing orders.
3
Provide dock leveler serial number, voltage, and phase when calling or faxing orders.
