PARTS
47 4111-0001 — Sept. 2010
Logic Block Assembly
Logic Block and Lever Arm
Item Quantity Part Number Description
A 1
9574-0001 Spool Valve, Logic Block, Standard
9574-0002 Spool Valve, Logic Block, Cold Weather
B 1
5455-0001 Lever Arm, Standard
5455-0004 Lever Arm, Cold Weather
Logic Block Cable Assembly
Item Quantity Part Number Description
C 1 7955-0001 Cable Subassembly, Logic Block
D 2 2101-0059 Washer, 1/4 in.
E 1 9572-0004 Spring
F 1 8102-0001 Weight, Logic Block Cable
G 2 9552-0001 Ball, Steel
H 2 2101-0032 Set Screw, Socket-Head, 1/4-20 UNC x 3/8 in.
1 5265-0002 Cable Weight Assembly, Logic Block (Includes Items C – H)
Logic Block Assembly
Item Quantity Part Number Description
J 4 9301-0112 Fitting, #8-ORB Male x #8-JIC Male
K 1 9572-0002 Plug, Spool Valve
L 2 9572-0003 Gasket, Spool Valve
M 1 9572-0004 Spring, Spool Valve
N 1 9572-0013 Dowel Pin, Cold Weather/Wash Down Feature Only
P 1 9575-0007 Logic Block, Complete (Includes Items A and K – N)
Q 1 2101-0014 Cap Screw, 5/16-18 UNC x 2 in.
R 1 2101-0039 Nylon Lock Nut, 5/16-18 UNC
Dual Lanyard Assembly (Optional)
Item Quantity Part Number Description
S 1 4261-0004 Ring, Pull
T 1 7952-0002 Clasp, Cable
U 1 7955-0001 Cable Subassembly
V 1 8102-0002 Weight
1 5265-0001 Cable Assembly (Includes Items S – V)
W 1 5405-0001 Lever Arm
X 1 2101-0068 Cap Screw, 5/16-18 UNC x 1-3/4 in.
Y 2 2101-0039 Nylon Lock Nut, 5/16-18 UNC
Z 5 2101-0163 Flat Washer, 5/16 in.
AA 1 2101-0015 Cap Screw, 5/16-18 UNC x 3-1/4 in.
