PARTS
44 4111-0001 — Sept. 2010
*Provide dock leveler serial number when calling or faxing orders.
Platform Cylinder Repair Parts
Item Quantity Part Number Description
A 1
0525-0048 Seal Kit 1992 and Newer
0525-0013 Seal Kit 1991 and Older
B 1 0525-0043 Cylinder, Platform, 15-1/2 in. (394 mm) Barrel Length
0525-0044 Cylinder, Platform, 17-1/2 in. (445 mm) Barrel Length
0525-0045 Cylinder, Platform, 19-1/2 in. (495 mm) Barrel Length
0525-0046 Cylinder, Platform, 21-1/2 in. (546 mm) Barrel Length
C 1 1751-0138 Decal
!
CRUSH HAZARD DO NOT REMOV safely supported b owner
’s/user
’s ma
procedure. Failure serious injury
.
A
B
C
