are properly located, add the replacement blade
(22) and screw in the blade bolt (23), tightening
it with the blade spanner (11).
Return the blade spanner (11) to its storage
position in the cable tidy (10).
Press down on the blade spanner (11) to lock it
in position under the retaining latch.
Return the mower to the upright position and
replace the grass box (19).
Reconnect the power cable to the supply and
run the mower for a few minutes to check that
the blade is properly fitted and that there is no
undue noise or vibration.
Use only the blade as recommended by the
manufacturer.
21
CLEANING THE FILTER
To help maintain good airflow within the grass
box and thus ensure optimum filling, regularly
check and, if necessary, clean the filter (27).
Access the filter by using a flat blade screwdriver
to prise off the filter cover (26).
22
Take out the filter, wash it in warm, soapy water,
rinse it and allow it to dry.
23
Clean out the filter area and replace the filter
and the filter cover (26).
NOTE. This filter is a consumable item and not
a warranty item.
24
MAINTENANCE
Store the tool, instruction manual and
accessories in a secure, dry place. You will
then always be able to refer to the relevant
information when required.
In order to take up less space when storing the
mower, loosen both wing knobs (9) and fold the
upper handle (1) over the lower handle (17).
When not in use, keep the cord wrapped
around the cable tidy.
Keep the tool’s air vents accessible when the
cover (13) is raised, unclogged and clean at all
times.
Remove dust and dirt regularly.
Clean inside the mower body and under the
deck. Use a brush or damp rag.
At the end of the season, give the mower
an overall cleaning and a thorough check,
including the blade. Have the blade sharpened
or replaced if necessary.
You can clean out the grass box with a hose or
pressure cleaner provided that you first remove
it from the mower. Replace the grass box when
it is dry.
Do not let water come into contact with the
motor.
Never use chemicals such as petrol or solvents
to clean plastic parts.
Never disassemble the tool or carry out any
repairs.
Always have the mower maintained or repaired
by a competent person at an authorised service
centre.
25
GENERAL INSPECTION
Regularly check that all fixing screws are tight.
They may vibrate loose over time.
26
PLUG REPLACEMENT
If you need to replace the fitted plug then follow
the instructions below.
IMPORTANT. The wires in the mains lead are
coloured in accordance with the following code:
Blue – Neutral Brown – Live
As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured markings identifying the terminals in
your plug, proceed as follows. The blue wire
must be connected to the terminal which is
marked with N or coloured black. The brown
wire must be connected to the terminal which is
marked with an L or coloured red.
WARNING. Never connect live or neutral wires
to the earth terminal of the plug.
Only fit an approved 13 Amp BS1363/A plug
and the correct rated fuse.
NOTE. If a moulded plug is fitted and has to
be removed take great care in disposing of the
plug and severed cable, it must be destroyed to
prevent engaging into a socket.
VII - Guarantee
Thank you for investing in MacAllister.
These products have been made to demanding,
high quality standards and are guaranteed for
domestic use against manufacturing faults for a
period of 36 months from the date of purchase.
To take advantage of this free extended
warranty please register on the website. This
guarantee does not affect your statutory rights.
If your product fails due to a defect in material or
workmanship during this period, please return it
to your nearest B&Q store.
Normal wear and tear, including accessory
wear, is not covered under guarantee. The
product is guaranteed for 12 months if used for
normal trade purposes. Any guarantee is invalid
if the product has been overloaded or subject
to neglect, improper use or an attempted
repair other than by an authorised agent.
Heavy duty, daily professional or hire usage
are not guaranteed. Due to continuous product
improvement, we reserve the right to change
the product specification without prior notice.
