36
Congratulations on your purchase of the Bosch Relaxx´x
vacuum cleaner.
This instruction manual describes various Relaxx´x
models, which means that some of the equipment fea-
tures and functions described may not apply to your
model. You should only use original Bosch accessories,
which have been specially developed for your vacuum
cleaner, to achieve the best possible vacuuming results.
Please keep this instruction manual for future referen-
ce. If you pass the vacuum cleaner on to someone else,
please also pass on this instruction manual.
Fold out the picture pages.
Your vacuum cleaner
1 Adjustable floor tool with accessory connection
2 Telescopic tube with sliding switch and accessory
connection
3 Accessories holder
4 Flexible hose
5 Handle
6 Brush ring (to fit on the upholstery nozzle)*
7 Parking aid on the side of the appliance
8 Power cord
9 Dust container
10 Upholstery nozzle
11 Crevice nozzle
12 "Clean" filter cleaning button*
13 Power level indicator
14 On/Off button with electronic suction regulator
15 Appliance lid
16 Carrying handle
17 Storage aid on the underside of the appliance
18 Plate filter
19 Fluff filter
20 Professional upholstery nozzle*
21 Professional crevice nozzle*
22 Hard-floor tool*
23 TURBO-UNIVERSAL® tool for floors*
24 Hard-floor tool*
Replacement parts and special acces-
sories
A TURBO-UNIVERSAL® tool for upholstery BBZ42TB
All-in-one brushing and vacuuming of
upholstered furniture, mattresses,
car seats, etc. Especially suitable for
picking up pet hair. The brush roller
is driven by the suction air flow
through the vacuum cleaner.
No separate electrical connection is
needed.
B TURBO-UNIVERSAL® tool for floors BBZ102TBB
All-in-one brushing and vacuuming of
rugs and carpets as well as all hard
floor coverings.
Especially suitable for picking up pet
hair. The brush roller is driven by the
suction air flow of the vacuum clea-
ner.
No separate electric connection is
needed.
C Hard-floor tool BBZ123HD
For vacuuming hard floors
(parquet, tiles, terracotta, etc.)
D Hard-floor tool BBZ124HD
With 2 rotating brush rollers
For caring for valuable hard floors
and improved collection of coarse
dirt.
Initial use
Figure
a) Push the flexible tube adapter into the air intake ope-
ning on the appliance and lock it in place. You will
hear an audible 'click'.
b)To remove the flexible hose, press the two catches
together and pull out the hose.
Figure
a) Push the handle into the telescopic tube. To remove
it, turn the handle slightly and pull it out of the tube.
b)Push the handle into the telescopic tube until it locks
into place. To release the connection, squeeze the
collar sleeve and pull the handle out.
1
2*
en
*
dependent on model
