S E R v I C E
ASC-2E & ASC-4E Electric Convection Ovens - Electronic Control • 22
Part numbers and drawings are subject to change without notice.
2
3
6
7
9
8
20
18
11
13
14
16
15
17
10
21
1
5
19
4
12
f u l l a S S E M B l y - a S c - 4 E
*Not Shown
ITEM
dESCRIPtIon
PARt no. QTy ITEM
dESCRIPtIon
PARt no. QTy
1
LATCH
LT-26976
2
14
MODULAR BLOCk
Bk-34684
1
2
DOOR ASSEMBLy, LH
DR-27850
1
15
TERMInAL BLOCk
Bk-3597
1
3
SIDE RACk
SR-26396
2
16
POWER SUPPLy
BA-33554
1
4
COVER, BOTTOM HInGE
1006678
1
17
RELAy
RL-33930
2
5
COVER, TOP HInGE
1006679
1
18
MOTOR RELAy
RL-33558
2
6
OVEn RACk
SH-26795
6
19
HIGH LIMIT
SW-34150
1
7
GASkET
top
/
bottom
1006606
2
20
PAnEL OUTER, RH
1006671
1
side
1000605
2
21
PAnEL OUTER, TOP AnD LH
1006623
1
8
FEET
see
pg
10
4
22*
PAnEL, LOUVERED ACCESS
1006672
1
9
DOOR ASSEMBLy, RH
DR-27849
1
23*
CORD
CD-34094
1
10
SWITCH, FAn, HI/LO
SW-34101
1
24*
FAn, BOx
34CFm, 230V, 50-60H
z
FA-3974
1
11
PAnEL OVERLAy
PE-26729
1
25*
BUzzER
Bz-34113
1
12
COnTACTOR
Cn-3731
2
26*
RECEPTICAL, LAMP
RP-3986
1
13
FUSE HOLDER
FU-34771
1
27*
BULB, 15W
LP-3686
1
FUSE, 15 AMP
FU-34772*
2
