ASC-2E & ASC-4E Electric Convection Ovens - Electronic Control • 8
I n S t A l l A t I o n
S T a c k I N g & v E N T I N g a S S E M B l y ( 2 - A S C - 4 E / S T K 2 0 8 / 2 4 0 V
S H O W N
)
After legs or casters have been installed
on the bottom oven, place the upper oven
on top of lower unit. Align.
ITEM dESCRIPtIon PARt no. QTy
2 RISER, FLUE ELECTRIC 1004984 1
3 SCREW, #10 SMS .5LG SC-26520 5
Note: Actual unit may be
different than shown.
2
3
Remove top elbow vent
prior to installing riser.
Assemble venting
components 2 & 3
as shown
C A U t I o n
tO PREVENt PERSONAL iNJURY,
USE CAUtiON WHEN MOViNg OR
LEVELiNg tHiS APPLiANCE.
Part numbers and drawings are subject to change without notice.
