SPECIFICATIONS
Microphone HSC 171 HSC 271 HSD 171 HSD 271, HSD 271 Single
Type: prepolarized condenser prepolarized condenser dynamic dynamic
microphone microphone
Polar pattern: cardioid cardioid hypercardioid hypercardioid
Frequency range: 20 Hz to 20 kHz 20 Hz to 20 kHz 60 Hz to 17 kHz 60 Hz to 17 kHz
Sensitivity: 25 mV/Pa 25 mV/Pa 1 mV/Pa (-60 dBV) 1 mV/Pa (-60 dBV)
Max. SPL for 1% / 3% THD: 126 dB/- 126 dB/- 124 / 128 dB 124 / 128 dB
Equivalent noise level: 22 dB(A) 22 dB(A) 15 dB(A) 15 dB(A)
Signal/noise ratio (A-weighted): 72 dB 72 dB - -
Electrical impedance: ≤ 200 ohms ≤ 200 ohms ≤ 600 ohms ≤ 600 ohms
Recommended load impedance:
≥ 2000 ohms ≥ 2000 ohms ≥ 2000 ohms ≥ 2000 ohms
Power requirement: 9 to 52 V phantom power 9 to 52 V phantom power - -
Current consumption: ≤ 2 mA ≤ 2 mA - -
Headphones
Type:
closed-back, supraaural closed-back, circumaural closed-back, supraaural closed-back, circumaural
dynamic headphones dynamic headphones dynamic headphones dynamic headphones
Sensitivity: 94 dB SPL/mW 94 dB SPL/mW 94 dB SPL/mW 94 dB SPL/mW
Frequency range: 18 Hz to 26 kHz 16 Hz to 28 kHz 18 Hz to 26 kHz 16 Hz to 28 kHz
Power rating: 200 mW 200 mW 200 mW 200 mW
Rated impedance: 55 ohms 55 ohms 55 ohms 55 ohms
THD: <0.4 % <0.3 % <0.4 % <0.3 %
System
Connector:
6-pin mini XLR connector 6-pin mini XLR connector 6-pin mini XLR connector 6-pin mini XLR connector
Cable: 2 x 3-conductor; separable; 2 x 3-conductor; separable; 2 x 3-conductor; separable; 2 x 3-conductor; separable;
10 ft. (3 m) long; coiled section; 10 ft. (3 m) long; coiled section; 10 ft. (3 m) long; coiled section; 10 ft. (3 m) long; coiled section;
with 6-pin female mini XLR with 6-pin female mini XLR with 6-pin female mini XLR with 6-pin female mini XLR
connector, 1/4" TRS jack plug connector, 1/4" TRS jack plug connector, 1/4" TRS jack plug connector, 1/4" TRS jack plug
(headphones), and 3-pin XLR (headphones), and 3-pin XLR (headphones), and 3-pin XLR (headphones), and 3-pin XLR
connector w/integrated connector w/integrated connector (microphone) connector (microphone)
HSC-PA phantom power HSC-PA phantom power
adapter (microphone) adapter (microphone)
Finish: matte black matte black matte black matte black
Weight: 250 g (8.8 oz.) 300 g (10.6 oz.) 255 g (9 oz.) HSD 271: 305 g (10.8 oz.)
HSD 271 Single: 265 g (9.4 oz.)
HSC Series: microphone frequency response and polar diagram HSD Series: microphone frequency response and polar diagram
