AKG Acoustics C 420 User Manual
C 420, Condenser microphone description, Features

C 420
Condenser Microphone
Description
The C 420 cardioid condenser microphone was designed
with a full frequency response bandwidth that delivers a pure,
powerful sound and carries punch and presence to the
audience. It is ideal for front vocalists, singing keyboard
players, drummers, guitarists, dancers, and aerobics
instructors. It has a new and fully adjustable headband and
earpieces that fit comfortably and securely on your head. The
C 420 has the cable exiting from the rear of the headband to
stay out of the way of your performance.
Features
• Behind-the-head band for comfort
and secure mounting
• Miniature gooseneck for precise
positioning
• External shock mounting for
freedom from interference
• Adaptable to phantom powering or
wireless operation
Specifications
Transducer type:
Condenser pressure gradient
Frequency response:
20 Hz - 20 kHz
Polar pattern:
Cardioid
Impedance:
200 ohms
Output connector:
XLR (C420), mini XLR (C420/L)
Sensitivity:
7 mV/Pa; -43 dB (re 1 V)
Powering:
Phantom powering from 9 to 52 Vdc
with power adapter
Sound pressure level for 1% /3% THD: 126/130 dB
Size:
4.9 in. (125 mm) x 5.0 in. (130 mm)
Net/Shipping weight:
1.1 oz./19.6 oz. (30 g/540 g)
Standard accessory:
W 44 Windscreen
Optional Accessories:
B 29 L battery operated phantom
power supply with a 2 input mixer
(used with the C 420 L version)
B 18 E battery operated phantom
power supply. (used with C 420)
B 15 battery operated power supply
