Section A: Specifications 4
A: S
PECIFICATIONS
Model Specifications
Model Standard
Capacity Heat Exchangers
Passive Active
Dimensions Weight Power
Supply
e5300 0-3 LPM
0-6 SCFH 1x5 in. 1x5 in. 11 x 7 x 11 in. HWD
29 x 18 x 29 cm HWD
20 lbs
9 kg
100W
e5400 3-4 LPM
6-8 SCFH 2x5 in. 11 x 7 x 11 in. HWD
29 x 18 x 29 cm HWD
20 lbs
9 kg
240W
e5500 4-7 LPM
8-15 SCFH 1x10 in. 1x10 in. 14 x 13 x 13 in. HWD
36 x 33 x 33 cm HWD
37 lbs
17 kg
240W
e5500XP 4-7 LPM
8-15 SCFH 1x10 in. 1x10 in. 14 x 13 x 13 in. HWD
36 x 33 x 33 cm HWD
39 lbs
18 kg
240W
e5800 7-10 LPM
15-21 SCFH 2x10 in. 14 x 13 x 13 in. HWD
36 x 33 x 33 cm HWD
37 lbs
17 kg
500W
e5800XP 7-10 LPM
15-21 SCFH 2x10 in. 14 x 13 x 13 in. HWD
36 x 33 x 33 cm HWD
39 lbs
18 kg
500W
e5900 10-20 LPM
21-42 SCFH 2x10 in. 2x10 in. 14 x 13 x 13 in. HWD
36 x 33 x 33 cm HWD
39 lbs
18 kg
500W
e5900XP 10-20 LPM
21-42 SCFH 2x10 in. 2x10 in. 14 x 13 x 13 in. HWD
36 x 33 x 33 cm HWD
41 lbs
19 kg
500W
General Specifications
Digital Boards Main control board
Water slip alarm relay board
LAN card (optional)
Filter probe & heated sample line accessory
board (optional)
Heat exchanger thermocouple isolated output
board (optional)
Alarms Probe over / under temperature
Heated sample line over / under temperature
Cooler over temperature
Cooler thermocouple failure
Water slip (moisture carryover)
Display Jumbo dual-line LCD
LED red, amber, green heat exchanger status
indicators
Heat Exchanger
Type EZ- Clean™ twist apart
Heat Exchanger
Material Stainless steel (standard); Durinert ® treated
stainless steel, Kynar ® , Glass (optional)
Heat Exchanger
Connections 1/4” FNTP Inlet (first heat exchanger)
1/8” FNTP Outlet
3/8” FNTP Drain
Heat Sink High heat transfer aluminum
Voltage 110/120 VAC, 220/240 VAC, 12 VDC, 15 VDC,
24 VDC
Digital Board Specifications
Main Control Board 4 thermocouple inputs
4 analog outputs
Water Slip Alarm Relay
Board 2 water slip (moisture carryover) inputs
2 high current digital contact outputs
2 digital PLC outputs
LAN card (optional) Modbus or TCP/IP
RJ45 / CAT 5 cable
Filter Probe & Heated
Sample Line Accessory
Board (optional) 2 thermocouple inputs
Pulse width modulated digital output
Heat Exchanger
Thermocouple Isolated
Output Board (optional) 2 thermocouple inputs
2 x 4-20mA outputs
2 x 0-10VDC outputs
Operating Specifications
Maximum Inlet Sample
Temperature 400  F (205  C) SS, Durinert ® , Glass Impingers
280

F (138

C) Kynar ® Impingers
Maximum Inlet Pressure 45 psig
3 bar / 2250 mmHg
Maximum Heat Exchanger
Pressure Drop <+1 in. H2O
Ambient Temperature
Range 33-104  F
0.6-40

C
Outlet Sample Gas Dew
Point 41

F
5

C
