Page 12
12
ASUS K7M User’s Manual
2. FEATURES
Motherboard Parts
2. FEA
TURES
Slot A
AMD North Bridge (AGP/PCI/Memory Controller)
ATX Power Connector
DIMM Sockets
IDE Connectors
Floppy Disk Drive Connector
USB Connector (Port 2 & Port 3) (optional)
Hardware Monitor Chip
VIA South Bridge (PCI Super I/O Integrated Peripheral Controller)
Programmable Flash EEPROM
Wake-On-Ring Connector
Wake-On-LAN Connector
ISA Slot(s) (1 or 2 slots, ISA model only)
PCI Slots (number optional at purchase time)
AC’97 Audio CODEC
AGP Slot
Audio Modem Riser (AMR) Connector
Joystick/MIDI Connector (
T
) /
Line Out, Line In, Microphone In Connectors (
B
)
Serial Connector (COM2) (
B
)
Parallel Port Connector (
T
)
Serial Connector (COM1) (
B
)
USB Connnectors (Port 0 & Port 1)
PS/2 Mouse (
T
)/Keyboard (
B
) Connectors
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
T
: Top
B
: Bottom
2.2 Motherboard Parts
See opposite page for locations.
