TRACEABLE

WORKSTATION

BAROMETER

WITH CLOCK

INSTRUCTIONS

WEATHER FORECAST

The weather forecast is based on the changes in

barometric pressure over the past 12 hours. The

weather forecast symbols do not necessarily reflect

the current weather conditions, they are a forecast

of future conditions. The accuracy of the weather

forecast is about 70 to 75%.
Forecast Symbol Meanings

clear partly cloudy light heavy

cloudy rain rain

TIME-OF-DAY ALARM/SNOOZE

1. While in the normal display mode, press the

+ or buttons to display and adjust the

time-of-day alarm time.

2. To activate the time-of-day alarm, move the

slide switch (located on the side of the unit) to

the “AL ON” position.
With the time-of-day alarm activated, when the

alarm time is reached the alarm will sound. Each

press of the SNOOZE button will silence the alarm

for 5 minutes (Zz will appear on the display).
To turn off the alarm, move the slide switch to the

“AL OFF” position.

DISPLAY ILLUMINATION

The unit features a back-light with 2 modes of

illumination for viewing in low light conditions.
Pressing the SNOOZE button will fully illuminate

the display for approximately 3 seconds.
Moving the slide switch (located on the side of the

unit) to the NIGHT LIGHT position (AL OFF or AL

ON) will provide a continuous low level illumination

of the display. (This level of illumination is only

visible under low light conditions).
ALL OPERATIONAL DIFFICULTIES

If the Altitude Adjustment is incorrectly set, it may

cause the barometric pressure reading to be

out-of-range. See the “Altitude Adjustment” section

and adjust the altitude to correct this difficulty. If

the temperature reading is out-of-range, the unit

must be placed in an environment that is within the

thermometer’s specified temperature range.
If this barometer does not function properly for

any reason, replace the batteries with new high

quality batteries (see the “Battery Replacement”

section). Low battery power can occasionally

cause any number of “apparent” operational

difficulties. Replacing the batteries with new fresh

batteries will solve most difficulties.

®

BATTERY REPLACEMENT

Erratic readings, faint readings, or no display are

all indications that the batteries must be replaced.

Remove the battery cover by sliding it in the

direction indicated by the arrow. Remove the

exhausted batteries and replace them with three (3)

new AAA alkaline batteries. Make certain to install

the new batteries in the directions indicated in the

battery cover. Replace the battery cover. When

the batteries are replaced, the barometer returns to

the default settings. The following will need to be

set after replacing the batteries: Time-of-Day/Date,

Units of Measure, and Altitude Adjustment.
WARRANTY, SERVICE, OR RECALIBRATION

For warranty, service, or recalibration, contact:

CONTROL COMPANY

4455 Rex Road

Friendswood, Texas 77546 USA

Ph. 281 482-1714 • Fax 281 482-9448

E-mail [email protected] • www.control3.com

Control Company is ISO 9001 Quality-Certified by DNV and

ISO 17025 accredited as a Calibration Laboratory by A2LA.

Control Company Cat. No. 1081

Traceable

®

is a registered trademark of

Control Company.

©

2013

Control Company.

92-1081-00 Rev. 0 070913
