4-20 Chapter 4: BIOS setup
SouthBridge Configuration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Options for SB HD
Azalia
SouthBridge Chipset Configuration
SP5100 CIMx Version : 5.5.0
SB Azalia Audio Configuration
SB Debug Configuration
OHCI HC (Bus 0 Dev 18 Fn 0) [Enabled]
OHCI HC (Bus 0 Dev 18 Fn 1) [Enabled]
EHCI HC (Bus 0 Dev 18 Fn 2) [Enabled]
OHCI HC (Bus 0 Dev 19 Fn 0) [Enabled]
OHCI HC (Bus 0 Dev 19 Fn 1) [Enabled]
EHCI HC (Bus 0 Dev 19 Fn 2) [Enabled]
OHCI HC (Bus 0 Dev 20 Fn 5) [Enabled]
SB Azalia Audio Configuration
HD Audio Azalia Device [Auto]
Enables the High Definition Audio Azalia devie.
Configuration options: [Auto] [Disabled] [Enabled]
HD Onboard PIN Config [Enabled]
This item appears only when you set the previous item to [Auto] or [Enabled],
and allows you to enable the HD Onboard PIN Config.
Configuration options: [Disabled] [Enabled]
Azalia Front Panel [Auto]
This item appears only when you set the previous item to [Enabled], and
allows you to enable or disable the Azalia Front Panel.
Configuration options: [Auto] [Disabled]
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Onchip HD Azalia Configuration
Advanced
HD Audio Azalia Device [Auto]
HD Onboard PIN Config [Enabled]
Azalia Front Panel [Auto]
SDIN0 Pin Config [Azalia]
SDIN1 Pin Config [Azalia]
SDIN2 Pin Config [Azalia]
SDIN3 Pin Config [Azalia]
Azalia Snoop [Disabled]
Azalia Clock Gating [Disabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Auto : When MIO is
installed then MIO
will be enabled.
