1 2 3 4
PUT FAR RIGHT SWITCH IN STANDBY POSITION (LOCATED ON RIGHT SIDE OF RADIO CONTROLLER)
5
PUSH RE-SET BUTTON (LOCATED ON LEFT SIDE OF RADIO CONTROLLER)
6
PRESS ENGINE START SWITCH, WHILE PULLING MANUEL CHOKE KNOB
7
RAMP THROTTLE TO DESIRED POSITION (LOCATED ON RADIO CONTROLLER)
8
ENGAGE CLUTCH SWITCH TO START DRIVE WHEEL (LOCATED ON THE RADIO CONTROLER)
9
DISENGAGE CLUTCH SWITCH TO STOP DRIVE WHEEL ( LOCATED ON THE RADIO CONTROLLER)
10
MUST BE IN STANDBY POSITION TO START AND IN THE RUN POSITION FOR CONTROLS TO WORK
CLUTCH
THROTTLE
50%
EMERGENCY ENGINE
RUN
ENGAGE
UP
TRACK
STOP
START
SPEED
RESET
CLUTCH
THROTTLE 100%
PUSH
ENGINE
STAND
BY
DIS-ENGAGE
DOWN
TRACK SPEED
IN
STOP
TURN IGNITION SWITCH TO THE ON POSITION (LOCATED ON MACHINE) TURN CLUTCH SWITCH TO THE ON POSITION (LOCATED ON MACHINE) DISENGAGE EMERGENCY STOP SWITCH (LOCATED ON RADIO CONTROLLER)
OPERATING INSTRUCTIONS FOR TRACK WIRE SA
W
23
