background image

ITEM

PART NO.

QTY.

DESCRIPTION

1

3200314

1

Nipple, 1/8" Quick Disconnect

2

3200315

1

Coupler, 1/8" Quick Disconnect

3

6040115

2

Hose Assembly 1/4" x 22" HP

4

3201663

2

Elbow, 1/4" M. Pipe to 1/4" M. JIC (45 deg)

5

2900064

2

Hair Pin Cotter, 3/4"

6

6010031

1

Cylinder Pin, 1" Dia. x 3" Long

7

2900002

3

Flat Washer, 5/8" SAE

8

2900113

1

Lock Washer, 5/8" Split

9

2900164

1

Cap Screw, Flange Hd., 5/8-11 x 1-1/2"

10

2900546

1

2 1/2" - 4 Hex Nut

11

2900350

1

2 1/2" Lock Washer Split

12

6040161

1

Angle Arm Mount Weldment

13

2900365

4

Lock Washer, 1" Split

14

2900370

4

1" - 8 x 3" Hex HD Capscrew

15

2500746

2

Bearing, 2" Innsert

16

2900026

2

1/2"-13 Jam Nut

17

2900058

4

1/2 FLAT WASHER

18

6040162

1

Angle Arm Weldment

19

2900307

1

Wing Screw, M6 x 16mm

20

2500211

1

Wrench, 15/16" Open End

21

2900433

1

Clevis Pin, 1" x 4"

22

2900440

1

Cotter Pin, 3/16" x 1-1/2"

23

6040009

1

Pivot Shaft

24

2900376

2

Cap Screw, Hex Head., 1/2-13 x 7"

25

6040160

1

Angle Arm Clevis

26

2501145

1

Hydraulic Cylinder

27

2900184

1

Grease Fitting, 1/4" NPT x 45 degree

Optional Angle Cutting Arm Assembly #6040159
