1 6041253 Aluminum Base w/chain 1
2 FE-1 4-25E1 10V Fein Motor 1 10V 60Hz with 5/8"-1 1 threads 1
3 IPT-DS03 Round Head Screw 10-24X1-1/4" 3
4 6041255 External Snap Ring for ER24 Bearing 1
5 6041256 Sprocket with 5/8"-1 1 threads 3
6 6041257 Plastic Spur Gear 1
7 6041258 Steel Spur Gear with 5/8"-1 1 Threaded 1
8 IPT-DS301X16 Plastic Cover Ring 1
9 IPT-DS09 Socket Head Cap Screw 1/4-20x2.0" SS 5
10 6041260 Cover Plate 1
11 6041261 Flat Head Tapping Screw 10x1.0" SS 3
12 6041262 Rigid Back Up Pad 5" with 5/8"-1 1 3
14 6041264 External Snap Ring for ER12 Bearing 3
15 IPT-TS78 Ball Bearing ER12 3
16 IPT-DS301116 Steel Ring 4.5" 2
17 6041267 Center Ball Bearing ER24 1
18 IPT-BHA Garden Hose Adapter 1
19 IPT-JGA Hose Fitting 3
20 IPT-CT14 Water Hose 1
21 6041271 Brass Ball Valve 1
22 6041272 Steering Wheel Cap 4
23 6041273 Bracket 1
24 6041274 Binding Head Screw 1/4-20x1/2" SS 6
26 6041276 Steering Wheel 1
27 6047206 Vacuum 90 Deg Ellbow 1
28 6047207 Vacuum Adapter 2-1/2" 1
29 IPT-DS301 129 Slurry Skirt 44" 1
32 6041279 Wrench 1
35 IPT-DS35 Shipping Container (Not shown) 1
36 IPT-DS36 WPO14-25E Air Adapter 1
DS3011 PARTS LIST 5/1/2012
FIG. PART NO. DESCRIPTION NO.
LIST REQ.
