DS301 OPERATING INSTRUCTIONS
Warning:
When using coolant, always use an outlet with a ground fault
circuit interrupter (GFCI).
1. Set the unit on its side and rotate the platens by hand to check for
rotation.
2. Apply the desired abrasive system to the platens.
3. Plug power cord into 110V, 60Hz, 20 Amp GFCI outlet.
4. Set speed control to “6” on the back of the unit.
5. Turn on switch. The planets will rotate at 2250 RPM. Most diamond
tools will perform best at this speed.
6. Do not operate the unit below speed 4 – the tool will overheat.
7. Do not use silicon carbide grinding stones or diamond cup wheels that
weigh over 1 lb.
8. Do not push the locking button on the Fein power unit during operation.
Driver Speed Platform Speed Platen Speed
1 150 RPM 750 RPM
2 210 RPM 1050 RPM
3 270 RPM 1350 RPM
4 330 RPM 1650 RPM
5 390 RPM 1950 RPM
6 450 RPM 2250 RPM
The DS301 is a versatile tool. Here are just a few uses:
Honing and polishing of limestone, marble, granite, glass, concrete counter
tops, stairs, walls and plastic.
Cleaning boat hulls and floors
Sanding of wood floors and dry wall seams
3
