Hydraulic Pump and Manifold
Part Number
Quantity
Description
2502569
1
Crank Shaft Pulley
2502511
1
Synchronous Belt, B-1400
2505054
1
Load Adapter Pulley
2505055
1
Bushing
3202196
1
Load Adapter Pulley
3200817
1
Load Adapter Gasket
2603301
1
Hydraulic Pump, 3.8 C.I.
3201233
1
Pump Flange, 2" FPT
3200810
1
Pump Flange, 1" FPT
3201299
1
Fitting, 2" MPT to 2" Hose Barb
3200751
1
Fitting, 1" FPT to 3/4" M. JIC
3200804
1
Fitting, 1/2" M. JIC to 5/8" M. O-Ring
3200758
1
Fitting, 1/4" MPT to 1/4" M. O-Ring
3202202
1
Fitting, Swivel Elbow, 1/4" MPT to 1/4" FPT
3200724
1
Hydraulic Pump Filter
3200720
1
Fitting, 3/8" M. JIC to 1/4" MPT
6011357
1
Belt Cover
6075058
1
Pump Mount Bracket
2903034
2
Set Screw, Square Head, 3/8-16 x 3"
3200740
1
Pressure Gauge
3201393
1
Fitting, Reducer, 3/4" MPT to 1/4" FPT
3200757
1
Fitting, Street Tee, 3/4" MPT x 3/4" FPT x 3/4" FPT
3200745
1
Fitting, Adapter, 3/4" M. O-Ring to 3/4" FPT
3200689
1
Manifold, ON/OFF
3200725
1
Fitting, Swivel Elbow, 3/8" M. O-Ring to 3/8" M. JIC
3200739
1
Fitting, 3/4" M. O-Ring to 3/4" M. JIC
3201003
1
Fitting, Elbow, 3/4" M. O-Ring to 3/4" M. JIC
3201306
1
Fitting, Plug, 3/4" M. O-Ring
3201610
1
Relief Valve, 3/4"
3201635
1
Manual Flow Control
3200778
2
Knob Kit
2502082
1
Flow Control, 12 Volt
3200763
1
Fitting, Hex Nipple, 3/4" MPT
2704855
1
Flow Meter
3202137
1
Fitting, Swivel Adapter, 3/4" MPT to 3/4" FPT
3200684
1
Fitting, Tee, 3/4" MPT
3200712
2
Ball Valve, 3/4"
3200744
1
Fitting, Connector, 3/4" M. JIC to 3/4" MPT
3200746
1
Fitting, Street Elbow 90, 3/4" MPT to 3/4" FPT
3201261
1
Fitting, Elbow, 3/4" M. JIC to 3/4" MPT
4
