Jackshaft Assembly #6013196A
Use #4641010
Use #6010150
Use #2500436
For saws prior
to May 2007:
(Use #6013120A for saws prior May 2007)
ITEM PART NO. QTY. DESCRIPTION
1 6013012 1 Jackshaft Mount R.H.
2 6013011 1 Jackshaft Mount L.H.
3 2500435 2 Pillow Block Bearing 2"
4 6013014 1 Jackshaft Brace
5 2900721 10 Flat Washer, 5/8" USS Hardened
6 2900113 4 Lock Washer, 5/8" Split
7 2900147 10 Cap Screw, Hex Hd., 5/8-11 x 1-3/4"
8 2900135 6 Lock Nut, 5/8-11 Nylon
9 2900129 2 Jam Nut, 1/2-13
10 2900541 2 Tap Bolt, Hex Hd., 1/2-13 x 2-3/4"
11 6013016 1 Jackshaft
12 6013112 1 Key, 1/2" Sq. x 5" Long
13 6011227 2 Key, 1/2" Sq. x 4" Bevel End Step
14 6010544 2 Sheave, 4" x 10 Groove w/Bushing
15 2502043 4 Banded Belt, 5/3VX450 - 5 Strand
16 6013036 1 Jackshaft Guard
17 2900022 5 Flat Washer, 5/16" SAE
18 2900031 5 Lock Washer, 5/16" Split
19 2900019 5 Cap Screw, Hex Hd., 5/16-18 x 3/4"
20 2501093 2 Bumper, 1"
21 2900172 2 Machine Screw, Rd. Hd., #10-24 x 1-1/4"
22 2900017 2 Lock Nut, #10-24 Nylon
