Blade / Engine Speed (RPM) Chart
Model CC6560 Concrete Saw
__________________________________________________________
WARNING:
Do not exceed Bladeshaft speed (RPM) shown for each blade size. Excessive Blade Speed
could result in blade breakage and serious personal injury.
Blade Size
Max Depth
of Cut
Blade Size Bladeshaft Engine
20” 7-5/8” No Load RPM Sheave Size No Load RPM Sheave Size
26” 10-5/8” 20” 2,425 4.50” 3,000 3.65”
30” 11-3/4” 26” 2,025 4.50” 2,500 3.65”
36” 14-3/4” 30” 1,650 5.60” 2,300 4.00”
36” 1,425 5.60” 2,000 4.00”
CAUTION:
When changing blade size, use chart shown below for selecting items that must be changed.
Model CC6560 20” 26” 30” 36”
Blade Guard Assembly 6010072 6010074 6010076 6010078
Engine Sheave, 1-3/4” Bore
(Sheave Size) 6010502
(3.65”)
6010502
(3.65”)
6010503
(4.00”)
6010503
(4.00”)
Bladeshaft Sheave, 1-3/4” Bore
(Sheave Size) 6010149
(4.50”)
6010149
(4.50”)
6010175
(5.60”)
6010175
(5.60”)
Engine Belts (8)
(Belt Size) 2500371
(3VX500)
2500371
(3VX500)
2500438
(3VX530)
2500438
(3VX530)
Inner Flanges
(Flange Size) 6010036
(4.50”)
6010036
(4.50”)
6010038
(6.00”)
6010038
(6.00”)
Outer Flange
(Flange Size) 6010037
(4.50”)
6010037
(4.50”)
6010039
(6.00”)
6010039
(6.00”)
Skid Plate 6010006 6010006 6010007 6010007
Options Available:
#6011032 Water Pump Kit - includes 12 Volt Pump, Toggle Switch, Hose and Fittings.
#6010112 Spotlight Kit - includes 12 Volt Light, Mounting Bar and Bracket, Lock Knobs, Toggle Switch.
#6010522 Water Safety Switch Kit – includes Safety Shut-off Switch, Relay, and Toggle Switch.
#6010179 Free Wheeling Clutch Kit – includes Clutch Sprocket and Hub, Engage/Disengage Lever, Linkage.
#6010227 Lowering Speed Metering Valve Kit - includes Metering Valve, Check Valve, Hydraulic Hose & Fittings.
#6011170 Magnetic Spotlight Kit – includes 12 Volt Light with Magnetic Base, Power Outlet, Toggle Switch.
#6010249 Extended Bladeshaft Kit (3/4” to 1-1/2”) – includes 4 -1/2” Extended Outer Flange, Bolt, 20” Extra Wide Blade Guard.
#6010229 Extended Bladeshaft Kit (1-1/2” to 2-1/4”) – includes Shaft Extension, 4 -1/2” Outer Flange, Nut, 20” Extra Wide Blade Guard.
#2501157 Catalytic Converter Kit – includes Catalytic Muffler.
