Blade / Engine Speed (RPM) Chart
Model CC6565 Concrete Saw
__________________________________________________________
WARNING:
Do not exceed Bladeshaft speed (RPM) shown for e ach blade size. Excessive Blade Speed
could result in blade breakage and serious personal injury.
Blade Size
Max Depth
of Cut
Blade Size
Bladeshaft
Engine
Governor
Setting
14”
4-5/8”
No Load RPM
Sheave Size
No Load RPM
Sheave Size
20”
7-5/8”
14”
2,900
4.12”
3,000
4.00”
10
26”
10-5/8”
20”
2,450
4.50”
2,750
4.00”
9
30”
11-3/4”
26”
1,950
4.50”
2,200
4.00”
6
36”
14-3/4”
30”
1,575
5.60”
2,200
4.00”
6
42” *
16-3/4”
36”
1,425
5.60”
2,000
4.00”
5
48” *
19-3/4”
42” *
1,050
7.60”
2,200
3.65”
6
48” *
960
7.60”
2,000
3.65”
5
CAUTION:
When changing blade size, use chart shown below for selecting items that must be changed.
Model CC6565
14”
20”
26”
30”
36"
42" *
48" *
Blade Guard Assembly
6010070
6010072
6010074
6010076
6010078
6010143
6010145
Bladeshaft Sheave, 1-3/4” Bore
(Sheave Size)
6010155
(4.12”)
6010157
(4.50”)
6010157
(4.50”)
6010113
(5.60”)
6010113
(5.60”)
6010283
(7.60”)
6010283
(7.60”)
Inner Flanges
(Flange Size)
6010036
(4.50”)
6010036
(4.50”)
6010036
(4.50”)
6010038
(6.00”)
6010038
(6.00”)
6013017
(8.00”)
6013017
(8.00”)
Outer Flange
(Flange Size)
6010037
(4.50”)
6010037
(4.50”)
6010037
(4.50”)
6010039
(6.00”)
6010039
(6.00”)
6013018
(8.00”)
6013018
(8.00”)
Skid Plate
6010006
6010006
6010006
6010007
6010007
6013038
6013038
Engine Base Mounting Holes
Rear Set
Rear Set
Rear Set
Front Set
Front Set
Front Set
Front Set
* Note: Items shown for 42” and 48” are for reference only. Use complete conversion kit #6010274 for 42” and #6010275 for 48”
when converting from 14” through 36”.
Options Available:
#6011032
Water Pump Kit - includes 12 Volt Pump, Toggle Switch, Hose and Fittings.
#6010112
Spotlight Kit - includes 12 Volt Light, Mounting Bar and Bracket, Lock Knobs, Toggle Switch.
#6010181
Oil Cooler Kit - includes Cooler, Oil Filter, Adapters, Hose and Fittings.
#2700143
Vertical Muffler Kit - includes Muffler, Clamp and Rain Cap.
#6010179 Free Wheeling Clutch Kit - includes Clutch Sprocket and Hub, Engage/Disengage Lever, Linkage.
#6047932
Water Safety Switch Kit – includes Safety Shut-off Switch and Toggle Switch.
#6010185
Side Plunge Kit - includes Bladeshaft, Flanges, and 20” Extra Wide Blade Guard.
#6010110
Outboard Bearing Kit - includes Flange Bearing, Support Plates, Spacer Tubes, Shaft Extension.
#6010226
Bladeshaft Tachometer Kit - includes Tach/Hour Meter, Magnetic Sensor, Gear, Wiring Harness.
#6010227
Lowering Speed Metering Valve Kit - includes Metering Valve, Check Valve, Hydraulic Hose & Fittings.
#6011170
Magnetic Spotlight Kit – includes 12 Volt Light with Magnetic Base, Power Outlet, Toggle Switch.
#6010299/300 Catalytic Converter Kit – includes Catalytic Muffler, Air Pump, Belt, Hoses, Pulley, Hardware.
#6010249
Extended Bladeshaft Kit (3/4” to 1-1/2”) – includes 4-1/2” Extended Outer Flange, Bolt, 20” Extra Wide Blade Guard.
#6010229
Extended Bladeshaft Kit (1-1/2” to 2-1/4”) – includes Shaft Extension, 4-1/2” Outer Flange, Nut, 20” Extra Wide Blade Guard.
#6010274
42” Blade Capacity Conversion Kit – includes Frame Base Extension, Bladeshaft Assembly, Belts & Pulleys, Belt & Blade Guards, Weights.
#6010275
48” Blade Capacity Conversion Kit – includes Frame Base Extension, Bladeshaft Assembly, Belts & Pulleys, Belt & Blade Guards, Weights.
