Diamond Products CC3500 (Gas) User Manual
Page 27
6011712 Parts List
ITEM
PART NO.
QTY.
DESCRIPTION
1
2900058
2
Flat Washer, 1/2" SAE
2
2900127
2
Flat Washer, 1/2" USS
3
2900026
4
Lock Nut, 1/2-13 Nylon
4
2900499
3
Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
5
2900288
1
Cap Screw, Button Hd., 1/2-13 x 2"
6
2900060
4
Cap Screw, Hex Hd., 3/8-16 x 2"
7
2900006
14
Lock Washer, 3/8" Split
8
2900018
6
Lock Nut, 3/8-16 Nylon
9
6011707
1
Engine Base Weldment CC3500J
10
2500159
2
Pillow Block Bearing, 3/4"
11
6011710
1
Pivot Plate, Jack Shaft CC3500J
12
2500731
2
Pillow Block Bearing 1-1/2"
13
6010034
1
Key, 3/8" Sq. x 5"
14
6011706
1
Jack Shaft, CC3500J
15
6011708
1
Belt Guard, Jack Shaft CC3500J
16
6048085
1
Idler Arm
17
2900321
3
Lock Washer, M10 Split
18
2900337
1
Cap Screw, Hex Hd., M10-1.5 x 50mm, Full Thd.
19
2900325
2
Hex Nut, M10
20
2900317
1
Cap Screw, Hex Hd., M10 x 45mm
21
2900304
1
Lock Nut, M10 Nylon
22
2900014
6
Flat Washer, 3/8" SAE
23
2500070
1
Spring, Extension, 3/4 Dia x 4
24
2900883
2
Cap Screw, Hex Hd., 5/16-18 x 5/8"
25
2900029
6
Cap Screw, Hex Hd., 3/8-16 x 1-1/2"
26
2900062
2
Grease Fitting, 1/8" NPT
27
2500074
1
Idler Pulley 3"
28
2900086
4
Cap Screw, Hex Hd., 1/2-13 x 1"
29
2900084
4
Lock Washer, 1/2" Split
30
2900104
1
Tap Bolt, Hex Hd., 5/8-11 x 6"
31
2900112
3
Hex Nut, 5/8-11
32
2900492
2
Tap Bolt, Hex Hd., 5/8-11 x 4"
33
2900446
2
Swivel Pad Nut, 5/8-11
34
3201276
4
1/4" Compression Tube Fitting
35
3201462
2
Nipple, 1/8" NPT X 1-1/2"
36
3200154
2
Pipe Elbow, 1/8" NPT Female
37
6011715
2
Grease Tube, 1/4" x 7"
38
2900473
2
Flat Washer, 3/8" USS
