Diamond Products CC1300XL (Gas) - Manual (Page 3)

Table of Contents
Description Page No.
Common Parts….…………………………………………………..……...4 - 5
Front Axle Assembly........………………………………………………...6
Screw Feed Assembly........………………………………………………..7
Engine Group – 8 Horsepower Honda.…………………………………....8 - 9
Engine Group – 11 Horsepower Honda.…..…………………………...…10 - 11
Engine Group – 11 Horsepower Honda for 20" Guard.…..……………....12 - 13
Engine Group – 9 Horsepower Robin.…..…………………………...…....14 - 15
Blade Shaft Assembly........……………………………………………… 16
14” Blade Guard Assembly........………………………………………….17
18” Blade Guard Assembly........………………………………………….18
20” Blade Guard Assembly........………………………………………….19
Pointer Assembly........….........…………………………………………....20
Water Tank Option Group..……………………………………………… 21
Notes…………….…………..…………………………………………… 22
Warranty………………..………………………………………………… 24
Quick Reference Service: Filters & Belts
DP Part No. Description Manufacturer’s Part No.
2702018 Air Filter for 8 & 11 HP Honda (Honda #17210-ZE3-505)
2704122 Air Filter for 9 HP Robin (Robin #279-32607-07)
2704148 Fuel Filter for 9 HP Robin (Robin #064-13600-10)
2500034 Belt for 8 HP Honda & 9 HP Robin (Gates #3VX315)
& 11 HP Honda with 20" Blade Guard
2500380
Belt for 11 HP Honda (Gates #3VX300)
