Blade and Jack Shaft Assembly
Part No. Qty. Description
2503451 1 Blade Shaft
2503469 2 Key
2503470 2 Inner Flange Key
2502886 2 Poly Chain Sheave 2 1/2" Bore
2503329 4 Blade Shaft Bearing 2 1/2"
2502944 2 Inner Blade Flange
2903052 12 Blade Bolts 3/8 - 16 x 1"
6048796 2 Outer Flange
2900146 1 5/8 - 11 x 4 RH Bolt
2900130 1 5/8 - 11 x 4 LH Bolt
2503452 1 Jack Shaft
2503466 1 Key
2503529 2 Bearing Spacer
2503331 1 5 Groove 21" Sheave
2503332 1 Bushing
2502776 1 Poly Chain Belt
8
