This insert is designed to convey the specifications of the P-16N and P-32N configured with a
natural gas regulator. This sheet is not designed to serve as the product manual.
Read and follow the PT Series Installation, Operation, Parts and Maintenance Manual that was
included with this product insert.
PT Series • Specifications • Warnings • Operating Values • Mounting
NOTE: Reference the installation, operation and maintenance manual (F/N: LIOPT) for installation
requirements.
Portable Heater Specifications for Natural Gas
Natural Gas
Operating Values
Model
No. BTU/H
Gas
Type
Minimum
Inlet W.C.
Maximum
Inlet PSI
Manifold
Pressure
Clearance to Combustibles
Sides Back Top Front
P-16N 16,000 Natural 7.0” 14 6.0” 18 in. 18 in. 48 in. 48 in.
P-32N 32,000 Natural 7.0” 14 6.0” 24 in. 18 in. 48 in. 72 in.
WARNING
!
!
In locations used for the storage of combustible materials, signs must be posted to
specify the maximum permissible stacking height to maintain the required clearances
from the heater to the combustibles. Signs must either be posted adjacent to the
heater thermostats or in the absence of such thermostats, in a conspicuous location.
Not for residential use! Do not use this heater in the home, sleeping quarters,
attached garages, etc. Installation of a commercial tube heater system in residential
indoor spaces may result in property damage, serious injury, asphyxiation or death.
This heater is designed to be operated under adult supervision at all times.
Mounting
With non-combustible materials, rigidly
mount the heater vertically (valve and
regulator at the bottom) using the 3/8”-16
thumbscrew provided to the mounting hole
located on the side of the heater.
All clearances to combustibles
must be
maintained at all times.
Mount
here
Side View Front View
F/N: LIOPTN-1c-07/06 (DRP)
Mount
here
