ADPT-NN-16/32
16-Electrode NeuroNexus Probe
Adapter for MPA32I Amplifiers
Important: Operation of the MPA32I is differential.
REF has to be connected for obtaining a proper signal.
Please see also the MPA32I manual for more details.
MPA32I 16-channel NN probe The indicated numbers are the ME-System channel numbers
that will be displayed in the MC_Rack program. The list beside
shows the assignment of the electrode numbers as given by
NeuroNexus Technologies.
GND is the ground, REF is the reference input of the miniature
preamplifier. Please see the MPA32I manual for details.
Optionally, it is possible to connect G1/G2 and GND together.
Pin layout of the input connector
1
2
3
4
5
6
7
8
REF
16
15
14
13
12
11
10
9
GND
plug
reference
electrode
here
plug
ground
electrode
here
Pin assignment
MPA32I MC_Rack Probe
Rev 2 Probe
Rev 3
REF
El. 16
El. 15
El. 10
El. 14
El. 8
El. 13
El. 6
El. 4
El. 2
El. 1
El. 3
El. 5
El. 7
El. 9
El. 12
El. 11
REF
El. 16
El. 15
El. 11
El. 14
El. 10
El. 13
El. 9
El. 8
El. 7
El. 6
El. 5
El. 4
El. 3
El. 2
El. 12
El. 1
Pin 17:
Pin 18:
Pin 1:
Pin 2:
Pin 5:
Pin 6:
Pin 7:
Pin 8:
Pin 9:
Pin 10:
Pin 11:
Pin 12:
Pin 13:
Pin 14:
Pin 15:
Pin 16:
Pin 3:
Pin 4:
Pin 19:
Pin 20:
Pin 21:
Pin 22:
Pin 23:
Pin 24:
Pin 25:
Pin 26:
Pin 27:
Pin 28:
Pin 29:
Pin 30:
Pin 31:
Pin 32:
Pin 33:
Pin 34:
Pin 35:
Pin 36:
Ch. 15
Ch. 16
(GND)
REF
Ch. 3
Ch. 4
Ch. 5
Ch. 6
Ch. 7
Ch. 8
Ch. 9
Ch. 10
Ch. 11
Ch. 12
Ch. 13
Ch. 14
Ch. 1
Ch. 2
(GND)
