ADPT-NN-16/32
16-Electrode NeuroNexus Probe
Adapter for MPA32I Amplifiers
Side view
The side with no screws is considered the top side of the MPA32I.
Connecting the 16-Channel NeuroNexus probe via Adapter ADPT-NN-16/32
to the Miniature Preamplifier MPA32I
NN-16 connector
MPA32I connector
Mounting possibility
for manipulator
NeuroNexus probe goes here
Bottom side
of the adapter
Bottom side
of the MPA32I
Warning: The device may only be used
together with the MPA32I from Multi
Channel Systems MCS GmbH and the
16-channel probe from NeuroNexus,
and only for the specified purpose.
Damage of the device and even fatal
injuries can result from improper use.
!
Please connect
the MPA32I with
the bottom side
(with screws)
facing to the bottom
side of the adapter
ADPT-NN-16/32.
