Signal dividers with
16, 32, or 64 channels SD16, SD32,
SD64 Placed between amplifier and MC_Card, permits to
select any channel, does not interfere with the data
acquisition
Signal grounding unit GND64 For silencing defective electrodes. Single channels can
be switched off with small toggle switches. Inputs not
in use are grounded.
Isolated power supply
with 10 W power and
± 6.3 V output voltage IPS10W Isolated power supply for integration into the data
acquisition computer. For supplying power
to amplifiers (MEA1060, MPA, FA).
Power supply with
40 W power and
± 7 V output voltage PS40W For supplying power to programmable gain amplifiers,
for custom setups that lack an internal power supply,
or for other custom applications
Digital in/out
extension Di/o For connecting other devices to single digital input and
output channels of the MC_Card via BNC connectors
(up to 16 inputs and 16 outputs), for example, for
synchronizing stimulation and recording,
or for applying feedback.
5.4 Add-ons for stimulation
Product Product
Number Description
2-Channel stimulus generator STG4002
4-Channel stimulus generator STG4004
8-Channel stimulus generator STG4008
Advanced stimulus generators for a very wide variety
of applications. For software controlled current and
voltage-driven electrical stimulation with integrated
stimulus isolation unit for each output channel.
Operating in Download and Streaming mode
(continuous down streaming of pulses from
connected computer). MC_Stimulus II software
program with advanced features.
5.4 Spare parts
Product Product Number Description
0.5 m 68-pin MCS standard cable C68x0.5M
1 m 68-pin MCS standard cable C68x1M
3 m 68-pin MCS standard cable C68x3M
Isolated power supply IPS10W
For (USB-) MEA- or ME-Systems
