ADPT-NN-32
32-Electrode NeuroNexus Probe
Adapter for MPA32I Amplifiers
Side view
The side with no screws
is considered the top side
of the MPA32I.
Please connect the MPA32I
with the top side up to the
bottom side of the adapter
as shown in the picture beside.
MPA32I
Top
Bottom
ADPT-NN-32
Input pins
NeuroNexus probe
Connecting the NeuroNexus probe and the MPA32I
Warning: The adapter may only be used
together with the MPA32I from Multi
Channel Systems MCS GmbH and the
32-channel probe from NeuroNexus,
and only for the specified purpose.
Damage of the device and even fatal
injuries can result from improper use.
!
