Multichannel Systems MEA-IT Manual - Manual (Page 9)

5
3 Setting up the MEA-IT
3.1 Hardware
The MEA-IT is a very compact and portable device for measuring electrode impedances
on microelectrode arrays (MEA) with MEA-IT software.
The measurements are transmitted to the connected computer via universal serial bus
(USB 2.0 Full Speed). Thus, it is possible to use any computer as a data acquisition computer,
also a laptop.
The device does not need an own power supply. Just connect it to an USB port of the
data acquisition computer and the blue LED on the right side of the front panel lights up.
The USB connector is located on the side panel of the device.
