sPeCIFICatIONs aND PerFOrMaNCe
sYsteM PerFOrMaNCe
sensor tube 2 /
3
” Saticon, magnetic focus,
electrostatic deflection
Horizontal resolution 350 tvl centre per picture height
(T.05 chart & high resolution
monitor)
sensitivity 350lx for full video
Minimum Illumination 200lx for a usable picture
Geometric distortion <2% (excluding lens)
Video output 1V p-p into 75 ohms, NTSC
signal to noise ratio 36dB (agc at minimum gain)
eNVIrONMeNt (CaMera HeaD)
accumulated dose 1MGy (H
2
O) [ 60 Co] (1 x 10 8 rads)
Maximum dose rate 1kGy per hour (1 x 10 5 rads per
hour)
Operating temperature 0°C to 40°C (32°F to 104°F)
storage temperature -25°C to 60°C (-13°F to 140°F)
Operating depth 60m (200ft) (water)
eNVIrONMeNt (CONtrOLLer)
Operating temperature 0°C to 40°C (32°F to 104°F)
storage temperature -25°C to 60°C (-13°F to 140°F)
Humidity 85%, non-condensing
CaMera HeaDs - rC991 CMB 6:1 ZOOM
Length (excluding connector) 304mm (12”)
Diameter 80mm (3.15”)
Lens 12 to 72mm, f/1.8NB
Focus range (in air) 800mm (42”) to infinity
Focus range (in water) 1.1m (39.37”) to infinity
Horizontal angle of view 40° to 7° (in air)
30° to 5° (in water)
CaMera HeaDs - rC991 CMK 6:1 ZOOM
Length (excluding connector) 304mm (12”)
Diameter 80mm (3.15”)
Lens 24 to 144mm, f/3.6NB
Focus rante (in air) 800mm (42”) to infinity
Focus range (in water) 1.1m (39.37”) to infinity
Horizontal angle of view 40° to 7° (in air)
30° to 5° (in water)
CaMera HeaDs - rC991 CMF 6:1 ZOOM WItH
MaCrO FOCus (FOr use WItH PaN aND tILt)
Length (excluding connector) 304mm (12”)
Diameter 106mm (4.17”)
Lens 12 to 72mm, f/1.8NB
Focus range (in air) 10mm (0.4”) to infinity (wide
angle with macro focus)
330mm (13”) to infinity (telephoto
with macro focus)
Focus range (in water) 15mm (0.5”) to infinity (wide
angle with macro focus)
440mm (17”) to infinity (telephoto
with macro focus)
Horizontal angle of view 40° to 7° (in air)
30° to 5° (in water)
OPtIONaL - rC991 FIXeD 25mm LeNs
Lens Non-browning 25mm with remote
iris facility f/2.5
Focus range 70mm (2.75”) to infinity (in air)
95mm (3.65”) to infinity (in water)
Horizontal angle of view 20° (in air)
15° (in water)
