Page 11 Parts And Instruction Manual
28” Mirage Propane Burnisher
ITEM PART NUMBER DESCRIPTION QTY
1 271033 12V BATTERY 1
2 271029 (+) BATTERY CABLE 16.5" 1
3 271032 BATTERY BOX BOTTOM COVER 1
4 271099 3/8-16 X 1/2" HEX BOLT 2
5 271026 BATTERY BOX BRACKET 1
6 271038 STARTER SOLENOID 1
7 271085 VELCRO TANK STRAP 1
8 271093 TANK STRAP BRACKET LOOP 2
10 271012 1/4-20 X 1 1/2" HEX BOLT 1
11 271011 THROTTLE CABLE 1
12 271076 20LB. LPG CYLINDER 1
13 271101 HANDLE GRIP 2
14 271074 3/8-16 X3" HEX BOLT 1
15 271080 LOCK PIN 1
16 271071 LEFT HANDLE BRACKET 1
17 271070 T-HANDLE 1
18 271072 RIGHT HANDLE BRACKET 1
19 271073 3/8-16 X 1" HEX BOLT 4
20 271002 HANDLE MAINFRAME 1
21 271100 3/8-16 STOVER LOK NUT 7
22 271031 BATTERY BOX TOP COVER 1
23 271030 (-) BATTERY CABLE 26" 1
24 271024 KEYSWITCH 1
25 271025 WIRE HARNESS 1
26 271013 1/4-20 FLANGE NUT 1
PARTS LIST FOR BUFFER HANDLE ASSEMBLY
HANDLE ASSEMBLY BOM
