23
Maintenance and Service
5.5 Cleaning the motor
protection filter
The motor protection filter, underneath
the filter compartment, must be
checked regularly for accumulation of
dirt and, when necessary, tapped clean
or replaced by a new one.
Proceed as follows to replace the motor
protection filter:
1. Open the filter compartment
(Fig. 8/1) and remove the protection
filter in accordance with Fig. 8.
2. Open up the filter support (Fig. 8/3),
remove the filter cloth (Fig. 8/2) and
clean it.
Ensure the motor protection
filter is fitted correctly because
this filter protects the air intake
section from dirt.
Fig. 8
2
3
1
