37
Maintenance and Care
Height Adjustment
The height adjustment is set to 3 mm at
the factory. If streaks are produced, de-
spite an optimum angle adjustment, the
clearance between the casters and
floor must be adjusted by changing the
number of washers on the holder.
In cases of very smooth floors, e.g. fi-
nished floors, PVC, linoleum, etc.
Number of washers = 2. This corre-
sponds to a clearance of approx. 2 mm.
In cases of very uneven floors, e.g.
poorly laid tiles (water does not run off)
Number of washers = 4. This corre-
sponds to a clearance of approx. 4 mm.
The Squeegee 110 cm (7569)
is equipped with two additional
rollers which are adjusted at
the factory to a distance of 10
mm to the floor by means of
spacers.
Fig.12
3 mm
2 mm 4 mm
