Parts and Instruction Manual
This manual is furnished with each new MINUTEMAN Ambassador™ 20. This provides the necessary
operating and preventive maintenance instructions. Operators must read and understand this manual
before operating or servicing this machine.
This machine was designed to give you excellent performance and efficiency. For best results and
minimal cost, please follow the general guidelines below:
· Operate the machine with reasonable care.
· Follow the manufacturers suggested maintenance instructions as provided in this booklet.
· Use original Minuteman supplied parts.
TECHNICAL SPECIFICATIONS
Model Ambassador TM 20
Model No. C8420-115 / C8420-240
Voltage (AC) 115V 60Hz ; 240V 50/60Hz
Current 12 Amps (115V) ; 7 Amps (240V) (50Hz)
Sound Level 79 dBA @ operator’s ear 73.6 dBA @ 3 meters
Brush Speed 1040 RPM
Dimensions (LxWxH) 45 1/8" x 20 3/4" x 38 1-4" (114.6cm x 52.7cm x 97.2cm)
Weight (gross) 234 lbs (106 kg)
