Minuteman 290 Series Stainless Steel Vacuum 4 & 6 Gallon - Manual (Page 2)

Parts and Instruction Manual
This manual is furnished with each new MINUTEMAN 290 Vacuum. This provides the neces-
sary operating and preventive maintenance instructions. Operators must read and understand
this manual before operating or servicing this machine.
This machine was designed to give you excellent performance and efficiency. For best results
and minimal cost, please follow the general guidelines below:
• Operate the machine with reasonable care.
• Follow the manufacturers suggested maintenance instructions as provided in this booklet.
• Use original Minuteman supplied parts.
Model No.
115V
230V
Power
Tank Size
Dry Capacity
Wet Capacity
Airflow
Waterlift
Decibel Rating
Weight
C29485-01
C29486-01
1.25 hp (1000W)
4 gal (15 ltrs)
.21ft³ (.006m³)
N/A
95 cfm (2.7m³/min)
85 in (2159mm)
68 db
25 lbs (11 kg)
C29685-01
C29686-01
1.25 hp (1000W)
6 gal (23 ltrs)
.46ft³ (.013m³)
4.5 gal (17 ltrs)
95 cfm (2.7m³/min)
85 in (2159mm)
74 db
26lbs (12 kg)
