Minuteman 290 Series Tip N Pour User Manual
Page 2

Parts and Instruction Manual
This manual is furnished with each new MINUTEMAN 290 Series Tip ‘N Pour. This provides the
necessary operating and preventive maintenance instructions. Operators must read and understand this
manual before operating or servicing this machine.
This machine was designed to give you excellent performance and efficiency. For best results and
minimal cost, please follow the general guidelines below:
·
Operate the machine with reasonable care.
·
Follow the manufacturers suggested maintenance instructions as provided in this booklet.
·
Use original Minuteman supplied parts.
TECHNICAL SPECIFICATIONS
Model
290 Series Tip ‘N Pour
Model No.
Power
Tank Size
Dry Capacity
Wet Capacity
Airflow
Waterlift
Decibel Rating
Weight
Casters
Wheels
C29020-06 (115V)
C29020-05 (240V)
1.25 hp (1000 watts)
20 gal (76 ltrs)
2.00 cu.ft (.06m³)
17 gal (65 ltrs)
95 cfm (2.7m³/min)
85” (2159 mm)
74 db
69 lbs (31 kg)
3” (8 cm)
8” (20 cm)
C29020-07 (115V)
C29020-08 (240V)
2 x 1.25 hp (2000 watts)
20 gal (76 ltrs)
2.00 cu.ft (.06m³)
17 gal (65 ltrs)
190 cfm (5.4 m³/min)
85” (2159 mm)
74 db
74 lbs (34 kg)
3” (8 cm)
8” (20 cm)
Optional Squeegee Assembly
470100
