Parts and Instruction Manual
Page 6
1 760131 1 MOLDED BAG RING- BLACK
2 805054 1 BAG, CLOTH BAG ONLY NEW STYLE
1 760231MCH 1 RING,BAG RETAINING
2 380046 1 BALL, HOLLOW RUBBER
3 380045CTD 1 CAGE FLOAT ASY
4 760234 1 BAG, LINT TRAP FILTER 10 X 9 1
5 760260 1 SPRING-RETAINER BAG
6 711203 4 BLT-HH 1/4-20 X .62
7 711519 4 WSR-FLT .25 X 1.01 X .06
8 711373 4 NUT-NYLOC 1/4-20
9 800273 1 GASKET, BAG RING EXP
10 829779 1 LIQ SHUTOFF PLATE GALVAN
11 384005 1 TUBE,INTAKE ZINC PLT
ITEM PART NO. REQ’D DESCRIPTION
ITEM PART NO. REQ’D DESCRIPTION
BILL OF MATERIAL - 805058
BILL OF MATERIAL - 110408
Cloth Bag Assembly
Water Shut-off Assembly
