Midlite CUSTOM 360° HDMI WALL PLATE - Manual

Custom 360° HDMI Adaptor
Wall Plate and Cable Adaptor
www.midlite.com
Warehouse: 866 Warren Street, Fall River, MA 02721
Offi
ce Mail: PO Box 70189, No. Dartmouth, MA 02747
tel 508.676.5169 / toll free 800.606.5169 / fax 508.861.0105
FEATURES:
• Field tested to be used in applications up to 12 meters
• Supported cable length from HDMI adaptor to A/V
component up to 2 meters
• 7" length cable to reduce connection strain and make
easy bend up or down in 2x4 and 2x6 wall construction
• Supported resolution 480p, 720p, 1080i, and 1080p
• Gold plated connector rotates 360º in increments
of 45°, to align with HDMI cable and minimizes
connection strain
• Connection is made parallel to the wall
• Contains “In Field” cut away panel for a second adaptor
installation
• Wall Plate made of High Impact ABS to resist cracking
• Incorporates Splitplate™ patented wall plate design
with snap fi t connection
• Contractor size wall plate to cover up all surface
imperfections surrounding low voltage box edges.
• CL3 rated cable for in wall use
• Available in White, Light Almond, Ivory, and Black
Patented Splitplate
design for easy
cable installation
Patent Pending
White Light
Almond
Black Ivor y
360º
A second adaptor
can be installed
by removing the
cut away panel
Part No. Description
Custom 360º HDMI Adaptor
360A-7-WH White Custom 360º HDMI Adaptor
360A-7-LA Light Almond Custom 360º HDMI Adaptor
360A-7-IV Ivory Custom 360º HDMI Adaptor
360A-7-BK Black Custom 360º HDMI Adaptor
Custom 360º HDMI Wall Plate
HDMI-1GWH White Custom 360º HDMI Wall Plate
HDMI-1GLA Light Almond Custom 360º HDMI Wall Plate
HDMI-1GIV Ivory Custom 360º HDMI Wall Plate
HDMI-1GBK Black Custom 360º HDMI Wall Plate
NEW!
