Instruction Manual
9 High Frequency Energy Control
Specifications
Model AT-2
Type H-PAS Hybrid Pressure Acceleration System,
2-way
Drivers Woofer 5¼” (135mm) long-excursion GLH* cone
Tweeter 1 1 ⁄
8
” (28mm) low-resonance soft dome with 4mm oversize
long-throw surround and integral back chamber/heatsink
Frequency Response 41-20kHz, +/-3dB
Nominal Impedance 6Ω
Crossover Frequency 2.2kHz
Crossover Type Parallel, 2nd-order LP, 3rd-order HP
Sensitivity 88dB
Recommended 20 – 150 Watts RMS
Amplifier Power
Dimensions w/ grilles 8 7 ⁄
8
x 15 5 ⁄
8
x 12 5 ⁄
8
"
(W x H x D) 227 x 397 x 321mm
Weight (ea) 23 lbs (10.4 kg) ea.
*Graphite Loaded Homopolymer
Specifications are those in effect at the time of printing. Atlantic Technology reserves
the right to change specifications or appearance at any time without notice. All other
trademarks are the property of their respective owners.
