Page 7
Instruction Manual
7
System Wiring
System Wiring
LEFT
TERMINAL STRAPS
IN PLACE
RIGHT
INPUT
HF
LF
INPUT
HF
LF
LEFT
RIGHT
LEFT
AMP FOR HIGH
FREQUENCIES
AMP FOR LOW
FREQUENCIES
RIGHT
INPUT
HF
LF
INPUT
HF
LF
TERMINAL STRAPS
REMOVED
Be sure to connect red (+) on the speaker to red (+) on the amplifier
and black (–) on the speaker to black (–) on the amplifier.
Figure 6
Conventional Connection
Figure 7
Bi-amp Connection
