How would you like to View your UPS today?
ControlRoom View
The ControlRoom View is the default view for 3
phase UPSs. It provides a comprehensive listing of
UPS metering data including inputs, outputs,
LED status indicators
Color-coded LEDs
draw attention
to UPS alarms
Input status panel
Incoming power
measurements from
utility provider
Battery status
panel
Keeps you informed
on vital UPS battery-
related information
Bypass/misc. panel
Displays important
status information -
stay informed of UPS
temperature, fan and
bypass status, etc.
View Logs
Check previously
occurred alarms and
status changes
Output Status Panel
Outgoing power
measurements (what
your UPS is feeding
the protected devices)
NEW
battery and UPS status information. Color-coded
LED status indicators draw attention to UPS alarms.
LanSafe v. 5 offers three user-friendly, custom
views for monitoring status, metering information
and the internal workings of a UPS. Each view
provides a different level of available data, allow-
ing various user groups to select the most com-
pelling and useful view for their specific needs.
Toolbar buttons
Quick-launch most
common tasks
Input voltage
meter
Battery runtime
Amount of time the
UPS can operate on
battery power
Active events
log
Advanced
Battery
Management
(ABM
® )
animated status
indicator Doubles
battery life by
charging only
when necessary
Load percent
Percent of maxi-
mum output load
the UPS supports
the number
increases when
new devices are
plugged into
the UPS
Output voltage
meter
LanSafe controller
name, location and
UPS model
Animated UPS
topology display
The default view for single phase UPSs is 3-D
PowerScope, which provides crisp, real-time ani-
mation of the power flow through the UPS com-
ponents. Status and metering information is intu-
PowerScope View
itively available at-a-glance in a graphical format.
UPS component topology is automatically detect-
ed depending on the UPS model used.
