GENERAL DESCRIPTION / SPECIFICATIONS
The Vapor Eliminator is an in-line self-venting chamber which is used in both portable and stationary Max fuel-measurement
systems. It is placed directly upstream of the flowmeter- separating gases resulting from the “boiling” of low vapor pressure
fuels, and removing air bubbles resulting from aeration of the fuel tank, or leaks on the sunction side of the pump. It ensures
that the flowmeter measures liquids only.
Specifications
Materials of construction:
Body
370-160-000 . . . . . . . . . . . . . . . . . . . . . . . . . . Aluminum (Gasoline, Diesel)
370-170-000 . . . . . . . . . . . . . . . . . . . . . . . . . . 303 Stainless (Gasoline, Diesel, Alcohols)
Valve Orifice . . . . . . . . . . . . . . . . . . . . . . . . . . . 303 Stainless
Valve Seal
370-160-000 . . . . . . . . . . . . . . . . . . . . . . . . . Flourel (Gasoline, Diesel)
370-170-000 . . . . . . . . . . . . . . . . . . . . . . . . . Special Nitrile (Gasoline, Diesel, Alcohols)
Float . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304 Stainless
Miscellaneous Levers . . . . . . 370-160-000 . . .Brass
370-170-000 . .304 Stainless
Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304 Stainless
Volume (approximately) . . . . . . . . . . . . . . . . . . . . . . . . . 202 cc’s
Maximum Inlet Flow rate (liquid plus entrained gases)*
Gasoline . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5250 cc/min
Alcohol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4375 cc/min
Diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3500 cc/min
Maximum Operating Pressure . . . . . . . . . . . . . . . . . . . . 100 psi
Supply Line Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4” or 3/8” tubing
Maximum Temperature of Fuel
Gasoline . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 0 F
Alcohol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 0 F
Diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 0 F
* NOTE: Flow rates approaching the maximum of the Inlet Port will reduce the vapor elimination capabilities.
