3. WIRE SPECIFICATIONS
BATTERY CHARGER:
Use only an authorized Battery charger, MAX JC928.
4. TECHNICAL DATA
1
NOISE
A-weighted single-event ------ LWA, 1s, d 86 dB
sound power level
A-weighted single event ------ LpA, 1s, d 76 dB
emission sound pressure
level at work station
These values are determined and documented in accordance to EN12549 : 1999.
2
VIBRATION
Vibration characteristic value - 1.8 m/s
2
These values are determined and documented in accordance to ISO 8662-11.
This value is a tool-related characteristic value and does not represent the influence to the hand-
arm-system when using the tool. An influence to the hand-arm-system when using the tool will, for
example, depend on the gripping force, the contact pressure force, the working direction, the adjust-
ment of main supply, the workpiece, the workpiece support.
3
RADIATED EMISSION 30-1000 MHZ
Class B
Product name
MAX lithium ion battery pack
Product code
JPL914
Battery type
Lithium ion battery
Nominal voltage
DC14.4 V (3.6V
× 4 cells)
Nominal capacity
3.0 Ah (3,000 mAh)
Charging time
(When charger JC928 is used)
Quick charging - Approximately 30 minutes (Approximately 90%
of capacity)
Full charging - Approximately 45 minutes at 77°F (100% of capacity)
Accessories
Pack cap (For preventing short circuit)
Weight
1.1lbs
Charging temperature
41°F to 104°F (5°C to 40°C)
Operating temperature
14°F to 104°F (-10°C to 40°C)
Operating humidity
80% RH
or less
NAME
MAX TIE-WIRE
MODEL
TW897A
DIAMETER
21GA. (0.8 mm)
LENGTH
312feet/coil
TIES PER COIL
RB397 Approx. 120 ties/coil
TIES PER CHARGE
Approx. 1400 ties/charge
