Magnum Venus Plastech PATRIOT SSB Auto - Manual

Patriot SSB Auto Instructions Issue 05 30/06//08 Page 1 of 43
Patriot SSB Auto
Commissioning and instruction and maintenance manual
Issue 05
CONTENTS
Section Description Page
1.0 Machine Overview 2
1.1 Health & Safety General Overview 3
2.0 Instrumentation and Control Familiarisation 4-7
3.0 Priming SSB Fluid Sections 7-9
4.0 Machine Operation 9-11
5.0 Shut down 11
6.0 Routine Maintenance 11
7.0 Maintenance 12
8.0 Patriot Resin Pump 16
9.0 Catalyst Pump, CAV,OP valve and ratio system 22
10.0 Injection Head & Mixer Assembly 32
11.0 Solvent Pump 33
11.2 Solvent automatic head valve 34
12.0 RGA Resin Gel Alarm 36
13.0 SSB Auto Machine Doctor 38
14.0 Additional Machine Connections 41
15.0 Machine Air Circuit 42
Revision history 43
