Amcor AMC 10KM-410 - Manual (Page 9)

9
GB
Never try to repair or dismantle the air conditioner yourself. Incompetent repairs result in
loss of warranty and can endanger the user.
Problem Cause Solution
The unit does
not function Check the plug fuse. Check
the mains outlet by connecting
another appliance Connect to a functioning outlet and
switch on
Water container indicator is on Empty water container
Room temperature outside
operating temperature range
The unit does
not seem to
perform In direct sunlight Close curtains
Windows or doors open, many
people or heat source in room
Dirty filter
Clean or replace filter
Air inlet or air outlet blocked Remove blockage
Room temperature lower than
selected value Change temperature selection
The unit is noisy Unit stands uneven Place on even surface (less vibrations)
The compressor
does not work Overheat protection probably
activated Wait until room temperature lowers
TROUBLE SHOOTING
Model AMC
7KM-410
AMC
10KM-410
AMC
12KM-410
Cooling capacity
measured conform EN 14511
BTU/h 6500 8300 9600
kW 1.9 2.4 2.8
Mains 220–240 V / 50 Hz / 1 phase
Power consumption W 690 830 1030
Current A 3.0 3.7 4.5
Dehumidification L/24h 24 28.8 36
Air delivery m 3 /h 300 350 350
Recommended room size m 2 12 18 24
Refrigerant type R410A
Compressor rotary
Fan speeds 2
Thermostat °C 18 – 32
Timer h 1 – 8
Dimensions (W x H x D) mm 377 x 750 x 400
Weight kg 29 30 32
Subject to modifications without prior notice. Please refer to the rating label for greater precision.
TECHNICAL DATA
