Page 25
CFH -4000 Series Heater Manual
Rev. 01/2013
Page | 25
Parts Drawings:
CFH-4000-AI
CLEAN FLOW HEATER – AIR INTERLOCK
CFH-4000-AIDS
DOUBLE STACK – CFH RESIN HEATERS
CFH-4000-B
BASIC CLEAN FLOW HEATER
CFH-4000-DBS
DOUBLE STACK – BASIC RESIN HEATER
CFH-5000
BASIC HEATER CORE ASSEMBLY
CFH-3050
PNEUMATIC PRE-HEAT SWITCH ASSEMBLY
