Magnum Venus Plastech High Volume Modular System User Manual
Page 8
Page 7 of 25
9.
Turn main air valve off.
10.
Relieve flush tank pressure until all air has exhausted from flush tank.
REMOVING MATERIALS FROM SYSTEM
NOTE: Remove fluid pressure before performing maintenance or disassembly.
1.
Disconnect resin pump from bulk resin system and allow to drain. Place inlet in
solvent or fill bulk system with solvent.
2.
Aim gun into container and open gun by pulling trigger. Keep trigger open.
3.
Open resin pump air valve and turn regulator until pump begins to stroke even, slow
strokes.
4.
When clean solvent exits gun, shut off regulator.
5.
Place container under resin pump accumulator and slowly unscrew the accumulator.
6.
Clean resin accumulator with solvent.
7.
Reinstall accumulator.
8.
Resin system can now be broken down for maintenance. Refer to Manual, Trouble-
shooting Guide and Parts Drawings for proper maintenance. Refer to page 30 of
Trouble Shooting Guide for filled system procedure and pages13 & 14 for long
period shutdown procedure.
