FRP SystemOne
Pumping System
Installation & Setup
Quick List Instructions
1.
Unpack unit & components
2.
Place unit & stand pipe in
base plate or portable cart (or
mount to wall with wall brackets)
Tighten bolts to secure
3.
Install catalyst jug
4.
Install resin surge chamber &
filter assembly
5.
Install manifold air hose to
power cylinder
6.
Attach hose fittings to resin
pump, catalyst pump, air &
flush tank
7.
Install boom to mast
(if applicable)
8.
Hang hose on boom
(if applicable)
9.
Attach pickup hose
10. Place flush tank in holder and
attach air hose from manifold
11. Double check all hose fittings
12. See start-up sheet and manual
for further instructions
Part No. M1100-1-2
